NGK SPARK PLUGS SPARK PLUG BR9ECM
1.570 RSD
Spark Plug
Superior construction for serious power
Versatile plugs with wide operating heat ranges prevent fouling from running too cool and preignition from running too hot
Features high alumina ceramics for improved heat dissipation and electrical insulation, deep-seated copper core for a wider heat range and a nickel alloy tip for longer life
Description
| HEAT RANGE | 9 |
| MODEL | Standard |
| TERMINAL CONFIGURATION | Solid Terminal |
| THREAD SIZE | 14 mm |
| STYLE | BR9ECM |
| TYPE | Resistor Type |
| UNITS | Each |
| PRODUCT NAME | Spark Plug |
| CENTER ELECTRODE TYPE | Standard |
| ELECTRODE TIP MATERIAL | Nickel Alloy |
| CENTER ELECTRODE PROJECTION | Non-Projected |
| THREAD REACH | 19,1 mm (3/4″) |
| HEX SIZE | 20,6 mm (13/16″) |
| GROUND ELECTRODE CONFIGURATION | Single |
| SPARK GAP | 0,8 mm (0,031″) |
| GROUND ELECTRODE SHAPE | Angled |
| ELECTRICAL RESISTANCE | 5k Ohms |
| SPARK GAP IMPERIAL | 0.031″ |
| SPARK GAP METRIC | 0.8 mm |
| Make | Model | Displacement | Year | Country | Engine | Info | Position |
|---|---|---|---|---|---|---|---|
| APRILIA | RS 250 | 250 | 1995 | EUROPE | 41 KW(56 PS) | ||
| APRILIA | RS 250 | 250 | 1996 | EUROPE | 41 KW(56 PS) | ||
| APRILIA | RS 250 | 250 | 1997 | EUROPE | 41 KW(56 PS) | ||
| APRILIA | RS 250 | 250 | 1998 | ALL | 40 KW(54 PS) | ||
| APRILIA | RS 250 | 250 | 1999 | ALL | 40 KW(54 PS) | ||
| APRILIA | RS 250 | 250 | 2000 | ALL | 40 KW(54 PS) | ||
| APRILIA | RS 250 | 250 | 2001 | ALL | 40 KW(54 PS) | ||
| APRILIA | RS 250 | 250 | 2002 | ALL | 40 KW(54 PS) | ||
| HONDA | NSR 250 R | 249 | 1994 | ALL | 29 KW(40 PS) | ||
| HONDA | NSR 250 R | 249 | 1995 | ALL | 29 KW(40 PS) | ||
| SUZUKI | RG 125 F Gamma | 125 | 1992 | ALL | 24 KW(33 PS) | ||
| SUZUKI | RG 125 F Gamma | 125 | 1992 | JAPAN | 24 KW(33 PS) | ||
| SUZUKI | RG 125 F Gamma | 125 | 1993 | ALL | 24 KW(33 PS) | ||
| SUZUKI | RG 125 F Gamma | 125 | 1993 | JAPAN | 24 KW(33 PS) | ||
| SUZUKI | RG 125 F Gamma | 125 | 1994 | ALL | 24 KW(33 PS) | ||
| SUZUKI | RG 125 F Gamma | 125 | 1994 | JAPAN | 24 KW(33 PS) | ||
| SUZUKI | RG 125 F Gamma | 125 | 1995 | EUROPE | 24 KW(33 PS) | ||
| SUZUKI | RG 125 F Gamma | 125 | 1995 | JAPAN | 24 KW(33 PS) | ||
| SUZUKI | RG 125 F Gamma | 125 | 1996 | EUROPE | 24 KW(33 PS) | ||
| SUZUKI | RG 125 F Gamma | 125 | 1996 | JAPAN | 24 KW(33 PS) | ||
| SUZUKI | RGV 250 KAT Gamma | 249 | 1991 | EUROPE | 38 KW(52 PS) | ||
| SUZUKI | RGV 250 Gamma | 249 | 1991 | EUROPE | 46 KW(63 PS) | ||
| SUZUKI | RGV 250 KAT Gamma | 249 | 1992 | EUROPE | 41 KW(56 PS) | ||
| SUZUKI | RGV 250 Gamma | 249 | 1992 | EUROPE | 46 KW(63 PS) | ||
| SUZUKI | RGV 250 KAT Gamma | 249 | 1993 | EUROPE | 41 KW(56 PS) | ||
| SUZUKI | RGV 250 Gamma | 249 | 1993 | EUROPE | 46 KW(63 PS) | ||
| SUZUKI | RGV 250 Gamma | 249 | 1994 | EUROPE | 46 KW(63 PS) | ||
| SUZUKI | RGV 250 Gamma | 249 | 1995 | EUROPE | 46 KW(63 PS) | ||
| SUZUKI | RG 125 U Wolf | 125 | 1992 | ALL | 24 KW(33 PS) | ||
| SUZUKI | RG 125 U Wolf | 125 | 1992 | JAPAN | 24 KW(33 PS) | ||
| SUZUKI | RG 125 U Wolf | 125 | 1993 | ALL | 24 KW(33 PS) | ||
| SUZUKI | RG 125 U Wolf | 125 | 1993 | JAPAN | 24 KW(33 PS) | ||
| SUZUKI | RG 125 U Wolf | 125 | 1994 | ALL | 24 KW(33 PS) | ||
| SUZUKI | RG 125 U Wolf | 125 | 1994 | JAPAN | 24 KW(33 PS) | ||
| SUZUKI | RG 125 U Wolf | 125 | 1995 | JAPAN | 24 KW(33 PS) | ||
| YAMAHA | TZR 250 R | 250 | 1989 | JAPAN | |||
| YAMAHA | TZR 250 R | 250 | 1990 | JAPAN | |||
| YAMAHA | TZR 250 R | 250 | 1991 | JAPAN | |||
| YAMAHA | TZR 250 R | 250 | 1992 | JAPAN | |||
| YAMAHA | TZR 250 RS | 250 | 1992 | JAPAN | |||
| YAMAHA | TZR 125 R | 125 | 1993 | EUROPE | |||
| YAMAHA | TZR 125 | 125 | 1993 | EUROPE | |||
| YAMAHA | TZR 125 SP | 125 | 1993 | EUROPE | 21 KW(29 PS) | ||
| YAMAHA | TZR 250 R | 250 | 1993 | JAPAN | |||
| YAMAHA | TZR 250 RS | 250 | 1993 | JAPAN | |||
| YAMAHA | TZR 125 | 125 | 1993 | JAPAN | 19 KW(26 PS) | ||
| YAMAHA | TZR 125 R | 125 | 1994 | EUROPE | |||
| YAMAHA | TZR 125 | 125 | 1994 | EUROPE | |||
| YAMAHA | TZR 125 RR | 125 | 1994 | EUROPE | 21 KW(29 PS) | ||
| YAMAHA | TZR 125 | 125 | 1994 | JAPAN | 19 KW(26 PS) | ||
| YAMAHA | TZR 250 RS | 250 | 1994 | JAPAN | |||
| YAMAHA | TZR 125 R | 125 | 1995 | EUROPE | |||
| YAMAHA | TZR 125 | 125 | 1995 | EUROPE | |||
| YAMAHA | TZR 125 RR | 125 | 1995 | EUROPE | 21 KW(29 PS) | ||
| YAMAHA | TZR 250 SPR | 250 | 1995 | JAPAN | |||
| YAMAHA | TZR 125 R | 125 | 1996 | EUROPE | |||
| YAMAHA | TZR 125 | 125 | 1996 | EUROPE | |||
| YAMAHA | TZR 250 SPR | 250 | 1996 | JAPAN | |||
| YAMAHA | TZR 125 R | 125 | 1997 | EUROPE | |||
| YAMAHA | TZR 125 | 125 | 1997 | EUROPE | |||
| YAMAHA | TZR 250 SPR | 250 | 1997 | JAPAN | |||
| YAMAHA | TZR 125 R | 125 | 1998 | EUROPE | |||
| YAMAHA | TZR 125 | 125 | 1998 | EUROPE | |||
| YAMAHA | TZR 250 SPR | 250 | 1998 | JAPAN | |||
| YAMAHA | TZR 125 R | 125 | 1999 | EUROPE | |||
| YAMAHA | TZR 250 SPR | 250 | 1999 | JAPAN | |||
| YAMAHA | TZR 250 R SP | 250 | 1991 | JAPAN | |||
| YAMAHA | TZR 250 R SP | 250 | 1992 | JAPAN | |||
| YAMAHA | TZR 250 R SP | 250 | 1993 | JAPAN | |||
| YAMAHA | TZR 250 R SP | 250 | 1994 | JAPAN |
